Microplex Solid F140

Solid F140
Contionuous Laser Printer

The SOLID F140 is a fast continuous laser printer for monthly print volumes of up to 750,000 pages (A4, 2-up) per month. It can handle print media up to 18 inches wide ..

The paper tray, which is included in the price of the device, holds up to 3,000 pages (64 g/m²). Roll-to-roll solutions can also be implemented using the optional GPIO interface..

Due to the straight paper path and the non-contact flash lamp fusing (cold fusing, flash fusing), thermally sensitive materials such as PE, PVC, adhesive labels etc. can also be processed.

PCL5 ensures compatibility with standard laser printers and connection to SAP®

In addition, the SOLID F140 directly replaces discontinued printers such as Printronix® L7032, IBM® Infoprint 3000, IBM® Infoprint 4000, IBM® Infoprint 6500, IBM® Infoprint 100, IBM® Infoprint 75, OCE® Variostream, Okidata® ML series and SOLID 32E with its multiple printer languages (emulations).


Ideal for:
  • Label batch printing also on sensitive media such as PE, PVC, etc.
  • Stickers, labels and tags
  • Lists, invoices, delivery notes and other business documents
  • Workflow documents (pick lists, production instructions, etc.)
  • Batch processing of mailings in 2-up operation
    •

Interested?

Order Now!
  • Most economical cold fusing printer with 17-inch width
  • Prints on paper, PVC, plastic, etc.
  • USB, Ethernet (10/100 Mbit) as standard
  • Laser and matrix printer compatible
  • SAP with the standard PCL5e emulation
  • Perfect control via Status Out
  • Optional IPDS emulation making it the printer of choice for IBM solutions
    •
Rated Voltage / Maximum current:
Technology Electrophotography (LED Array), OPC Drum and Heat/Pressure Fuser
Print Speed 44 pages/minute (Letter landscape),
up to 34 pages/minute (Letter), Up to2.267 ips (inches/second)
Resolution in DPI Maximum 600 dpi x 600 dpi (dots / inch)
Duty Cycle (monthly) 50,000 pages per month (Letter, landscape)
Rated Voltage / Maximum current: 100-110V AC, 50 – 60 Hz / 15 Amps
110-120V AC, 50 – 60 Hz / 12.5 Amps
220-240V AC, 50 – 60 Hz / 6.5 Amps
Power Consumption Operating < 800 W average (< 1,300 W max)
Stand-by < 110 W average (< 1,200 W max)
Sleep < 45 W average
Noise (standby/operating): <42 / <60 dB (A)
Dimensions 21.2” (539 mm) x 19.6” (498 mm) x 23.1 (780 mm)
(W x H x D) (inclusive tractor cassettes)
Weight 88.2 lbs. (40 kg) including imaging cartridge



















Media Handling

Type Continuous forms / media with tractor pin holes
Paper Input from front with use of Tractor-feed Assembly
Paper Output out top, directed to the rear with media guide
Media Width min. 4 inch, max. 12 inch (print area, 11 inch)
Media Length F44 Printer w. iPS F44 min. 7 inch, max. 17 inch
F44 Printer, only min.3 inch, max. 20 inch
Media Weight 64 g/m² up to 157 g/m²











Print Languages / Emulations

Emulations HP LaserJet 4 (PCL 5e, PJL), HP – GL/2, PCL/PJLExtensions (Optional data stream Converter available for IPDS.)
Drivers Windows 3.x/95/98/NT/2000/XP/7, and Linux. Printer Configuration Software (Windows 95/98/NT, 2000/XP/7 and Linux) Profiler, Profile Selector and SAP R/3 device types, are available upon request.
Fonts 45 scalable fonts, 10 bitmap fonts
Barcodes Code 39, Code 93, Code 128, Codabar, 2/5 industrial, 2/5 interleaved, EAN 8/13 Add on 2/5, Postnet, MSI, UPC-A, UPC-E, KlXCode, Datamatrix Code











Interfaces

Standard 10BaseT/1 Ethernet, 00BaseTX, Parallel IEEE 1284 and USB 2.0 (in development)
