IR Interactive Whiteboard 70 Series

Six points touch bring maximum 6 students collaboration at the same time. Teachers can design more interactive lessons and students will be even more engaged in the learning process.


Features:
  • 4:3 and 16:10 aspect ratios available
  • Patented I-AVST Infra Ray (IR) multi touch technology - Make it a powerful tool in the classroom to add interactivity and collaborative learning
  • Support 10 points touch - Up to ten students can collaborate without boundaries and get more interactive learning experience.
  • Work with different platforms- Windows OS no driver is needed (HID device - plug & play);
  • MAC and Linux drivers available upon request
  • Standard marker pen writable surface - Uses a normal whiteboard and cleans without residual, even provides low-gloss surface optimized for projection
  • Optional ceramic surface available for anti-scratch function
  • Eco Friendly - Low power consumption through USB port
  • Robust Design - Robust mechanical design for long lifetime


Order Now!
Model Number IR70-78 IR70-88
Technology IR IR
Active Area Size(")  81.9" 92.2"
Projection Size(")    77.1" 87.3"
Projection Area *(mm) 1567mm*1165mm 1880mm*1165mm
Aspect Ratio 4:3 16:10
hot keys  Two sides Two sides
Frame Type  Alloy Frame Alloy Frame
Multi-Touch 10 points 10 points
Input Finger or Pen Finger or Pen
Pen Tray Simple Pen Tray Simple Pen Tray
Resolution 32767*32767 32767*32767
Scan Rate 125dot/ Second 125dot/ Second
Accuracy 1mm 1mm
Interface USB USB
USB Type A-B A-B
USB length in standard package 7.5m 7.5m
Power consumption (W) < 0.5W <0.5W
Support OS


Win 7/Win 8 32bit or 64bit
MAC OS


Win 7 /Win 8 32bit or 64bit
MAC OS

Operation Temperature(℃) 0-40℃ 0-40℃
Operation Humidity(%) 10~95% 10~95%
Storage Temperature(℃) -40-60℃ -40-60℃
Storage Humidity %) 10~95% 10~95%
LxWxH(mm) 1816*1275*57.8(mm) 2126*1275*57.8(mm)
Package Size (mm)  2070*1380*90 2240*1510*90
N.W(Kg) 20 22
G.W(Kg) 34 36
